基于BIM技术的铁路变配电所线缆敷设优化

朱超平; 刘珍珍; 郑云水

基于BIM技术的铁路变配电所线缆敷设优化

1. 中国铁道科学研究院集团有限公司通信信号研究所, 北京 100081;
2. 兰州交通大学自动化与电气工程学院, 兰州 730070

基金项目:

中国铁道科学研究院科研项目(2017YJ007)

详细信息

作者简介:
朱超平,助理研究员;刘珍珍,助理研究员。

中图分类号: U224;TP39
计量
- 文章访问数: 48
- HTML全文浏览量: 28
- PDF下载量: 13
出版历程
- 收稿日期: 2019-10-27

BIM technology based cable laying optimization of railway substation

1. Signal & Communication Research Institute, China Academy of Railway Sciences Corporation Limited, Beijing 100081, China;
2. College of Automation and Electrical Engineering, Lanzhou Jiaotong University, Lanzhou 730070, China

摘要

摘要: 为解决传统方法在铁路变配电所敷设施工时完全依靠二维设计布线图纸,易发生扭绞、交叉以及浪费物料等问题,基于建筑信息模型(BIM,Building Information Modeling)技术对铁路变配电所的线缆敷设进行优化。利用改进的快速扩展随机树(RRT^*,Rapidly Exploring Random Tree^*)算法,在三维视图下进行智能布线,解决了线缆布放规划复杂,工艺要求高,施工工艺难以掌握等问题,避免了施工过程中扭绞等问题的发生,同时实现了布线路径最优化。此外,还可以三维动画的形式对整个线缆敷设过程进行模拟和演示,并生成包含路由、长度、规格型号的线缆清单,显著提高了施工效率和工艺质量。
- 建筑信息模型(BIM) /
- 铁路变配电所 /
- 智能布线 /
- RRT^*算法
Abstract: The traditional method completely relies on two-dimensional design wiring drawings in the laying construction of railway substation. In order to solve the problems such as twisting, crossing and waste of materials, which are easy to occur when the traditional method is used in the laying construction of railway substation and distribution, the cable laying of railway substation and distribution was optimized based on BIM (Building Information Modeling) technology. Using the improved rapid exploring random tree (RRT^*, Rapid Exploring Random Tree^*) algorithm, the intelligent wiring was carried out in three-dimensional view, which solved the problems of complex cable layout planning, high process requirements, difficult to master the construction process, avoided the occurrence of twisting in the construction process, and implemented the optimization of wiring path. In addition, the whole cable laying process could be simulated and demonstrated in the form of three-dimensional animation, and a cable list including route, length, specification and model could be generated, which significantly improved the construction efficiency and process quality.
- Building Information Modeling(BIM) /
- railway substation /
- smart wiring /
- Rapid Exploring Random Tree^* (RRT^*) algorithm
