Improvement of display scheme of hump auxiliary repeater signal
-
摘要: 6502电气集中电路是铁路信号联锁系统、联锁逻辑的重要基础。针对6502电气集中电路中驼峰辅助复示信号在驼峰辅助信号开放前进信号后呈现闪光信号的问题,分析驼峰辅助复示信号显示电路的工作原理,研究驼峰辅助复示信号出现闪光信号的原因;从驼峰辅助信号前进信号灯丝断丝是否驱动LXJ的角度提出了4种修改方案,比较了4种方案对原6502电气集中电路的修改范围;以阜阳北三场为应用对象进行试验,结果表明,方案4满足故障-安全的处理原则,可为后续联锁软件相关问题的修改提供参考。Abstract: The 6502 electric centralized circuit is the important foundation of railway signal interlocking system and interlocking logic. In view of the flash signal of the hump auxiliary repeater signal in the 6502 electric centralized circuit after the hump auxiliary signal opens the forward signal, this article analyzed the principle of hump auxiliary repeater signal display circuit, and studied the cause of the flash signal of the hump auxiliary repeater signal. From the point of view of whether the break of the advance signal filament of the auxiliary signal of the hump drives the LXJ, the article put forward four modification schemes, and compared the modification range of the original 6502 electric centralized circuit by four schemes, carried out the test in the North Fuyang Three Field. The results show that scheme 4 meets the fault - safety processing principle, which can provide reference for the modification of the subsequent interlocking software related problems.
-
-
[1] 马小玲,张友鹏,杜求茂,等. 计算机联锁系统的可靠性和安全性比较[J]. 铁路计算机应用, 2009, 18(6):46-49. [2] 刘喜菊. 驼峰复示信号机点灯电路的改进[J]. 铁道通信信号, 2005, 41(4):18-19. [3] 黄振玉,裴士源,滕为国. 到达场与驼峰场联系电路的改进[J]. 铁道通信信号, 1997(12):26-27. [4] 王红兵,张玉金. 关于到达场与驼峰联系电路的探讨[J]. 铁路通信信号工程技术, 2004(4):15-16. [5] 朱成芳. 发车进路兼驼峰复示信号机点灯电路[J]. 哈铁科技通讯, 1988(3):5-6. [6] 国家铁路局. 集中联锁结合电路一般原则:TB/T 2307-2017[S]. 北京:中国铁道出版社, 2017. [7] 何文卿,王大地. 6502电气集中电路[M]. 北京:中国铁道出版社, 2018:251-266. [8] 沈岳光. 驼峰复示信号必须具备重复开放功能[J]. 铁路通信信号设计, 1996(2):1-2. [9] 国家铁路局. 铁路车站计算机联锁技术条件:TB/T 3027-2015[S]. 北京:中国铁道出版社, 2015.
