城市轨道交通车辆乘客载荷检测方法及试验应用

基金项目: 北京市科委科技创新基地培育与发展工程项目（Z131110002813122）; 北京地铁运营有限公司科研项目（2012200510000002）

详细信息

Method of passenger load detection and experimental application for vehicle of Urban Transit

Subway Operation Technology Centre, Mass Transit Railway Operation Corporation LTD, Beijing 102208, China

摘要: 在分析现有客流统计方法不足的基础上,提出通过采集车辆四个空气弹簧压力计算城市轨道交通车辆运行过程中乘客载荷的方法,分别通过三通阀改装及提取BCU控制箱预留信号获取空簧压力信号。在此基础上开展正线试验,采集正线运营车辆的乘客载荷信息,通过采集波形、数据提取、载客量转换及结果分析,计算测试周期内乘客数,满足车辆乘客载荷计算及安全性分析的需求。
- 城市轨道交通车辆 /
- 载荷检测 /
- 三通阀 /
- BCU /
- 超载
Abstract: Based on disadvantage analysis of existing passenger flow statistical method, the method of passengers load detection through collecting the pressure of four air springs of the vehicle was put forward. By conversing a three-way valve and extracting the obligating signal of BCU control, the signal of air spring pressure was obtained. The online test was taken through collecting waveform, extracting data, converting trainload and analyzing the results, the number of passengers within the testing period was calculated which could meet the requirements of load calculation and safety analysis.
- vehicle of Urban Transit /
- load detection /
- three-way valve /
- BCU /
- overload

[1]	H.Riener,D.PeiskalrLrner,W.Witteveen.Modal durability analy- sis of a passenger cars front suppoting frame due to full vehicle simulation loads[C]. Adams user conference, North America, 2001.
[2]	K,S.Kirn,H.J.Yim,C.B.Kim .Computational durability prediction of body structure in prototype vehicle[J]. International Journal of automotive technology, 2002(3):129-136.
[3]	刘志明.随机载荷下焊接构架疲劳寿命及可靠性研究[D].北京：北方交通大学,2001.
[4]	王连森.机车走行部运行可靠性研究[J].内燃机车,2010 （1）：8-11.
[5]	肖楠,谢基龙,周素霞.城市轨道交通车轮踏面制动疲劳强度评价方法及应用[J].工程力学,2007,27 （9）：234- 239.
[6]	曾全君.地铁车辆车轮寿命分析[J].电力机车与城轨车辆, 2005,28（2）：47-49.
[7]	汪洋.地铁列车车轮踏面环状剥离的分析[J].电力机车与城轨车辆,2003, 26（4）：67-68.
[8]	邓志刚,孙纲.地铁车辆车轮异常磨耗测试分析[J].现代城市轨道交通,2009（1）：19-22.
[9]	李熙.超载模式下城市轨道交通车辆走行部安全性分析及维修辅助决策[D].北京：北京交通大学,2014.
[10]	潘浩.基于双目视觉的客流检测与跟踪技术的研究[D]. 上海：上海交通大学,2009.
