Decision-making method of railway line main technical standards based on case base
-
摘要: 为解决线路主要技术标准的方案决策优化问题,提出了基于案例库的线路主要技术标准决策方法。通过收集大量的既有选线实例,分析线路主要技术标准的影响因素及作用机理,提取出主要的影响因素。将各类影响因素划分为不同的属性单元,由属性单元与主要技术标准之间的关系设计入库规则,建立基于GIS的线路主要技术标准案例库。以新建天水—陇南铁路为例对该方法进行验证,由查询语句实现线路的主要技术标准选定,与传统方法相比提高了科学性。
-
关键词:
- 主要技术标准 /
- 案例库 /
- 地理信息系统(GIS) /
- 方案决策
Abstract: In order to solve the decision-making optimization of main technical standards of the railway, this paper proposed a decision-making method based on case base. Through collecting a large number of existing railway decision cases, analyzing the influencing factors and action mechanism of the main technical standards of the railway, the paper extracted the main factors, divided the influencing factors into different attribute units, designed the rules of inputting into the database by the relationship between attribute units and main technical standards. The case base of main technical standards for lines based on GIS was established. Taking the newly built Tianshui-Longnan Railway as an example, the method was validated. The main technical standards of the line were selected by query sentences, which improved the scientific nature compared with the traditional method.-
Keywords:
- main technical standards /
- case base /
- GIS /
- decision-making
-
-
表 1 坡度组成分类及统计
分级Si 像元统计 比例/% 面积/km2 ≤15° 2 607 32.59 6.52 16°~35° 3 128 39.10 7.82 35°~45° 1 346 16.82 3.365 ≥46° 919 11.49 2.298 总计 8 000 平均坡度:25.53 -
[1] 夏明雷.新疆巴伦台至开特勒铁路关键技术标准研究[J].铁道工程学报, 2013, 30(5):7-11, 22. DOI: 10.3969/j.issn.1006-2106.2013.05.002 [2] 刘猛.山区高速铁路主要技术标准的研究[D].成都: 西南交通大学, 2012. [3] 陈健坤.巴新铁路主要技术标准的选择[J].铁道标准设计, 2009(3):24-26. DOI: 10.3969/j.issn.1004-2954.2009.03.008 [4] 王兴华, 李永庆.邯郸至黄骅港铁路关键技术标准研究[J].铁道工程学报, 2009, 26(6):13-16, 24. DOI: 10.3969/j.issn.1006-2106.2009.06.004 [5] 程永跃.兰渝铁路主要技术标准的综合优化研究[D].成都: 西南交通大学, 2008. [6] 陈小全.京九铁路客运专线速度目标值研究[J].铁道标准设计, 2015, 59(10):33-37. DOI: 10.13238/j.issn.1004-2954.2015.10.008 [7] Xue B, Chen X P, Geng Y, et al.Emergy-based study on ecoeconomic system of arid and semi-arid region-case of Gansu province, China[J].Journal of Arid Land, 2010, 2(3):207-213. DOI: 10.3724/SP.J.1227.2010.00207
[8] 张野, 韩峰.基于GIS的西北地区铁路路网扩张规律研究[J].铁道标准设计, 2017, 61(10):57-60. DOI: 10.13238/j.issn.1004-2954.2017.10.013 [9] 郑毛祥, 李鹏.江苏省中长期铁路网规划研究[J].铁道标准设计, 2017, 61(6):68-72. DOI: 10.13238/j.issn.1004-2954.2017.06.015 [10] 张开广, 巴明廷, 孟红玲, 等.河南省高速交通网通达性时空特征及演化规律[J].测绘科学, 2017, 42(6):87-92. DOI: 10.16251/j.cnki.1009-2307.2017.06.016 [11] 王妍, 刘洪斌, 武伟, 等.基于GIS的三峡库区地貌形态信息统计分析[J].测绘科学, 2006(2):93-95, 7. DOI: 10.3771/j.issn.1009-2307.2006.02.032 [12] 杨勤科, 郭兰勤, 王春梅.基于ASTRE和SRTM高程数据的坡度和坡长提取与分析[J].水土保持通报, 2012, 32(6):142-146. http://www.cnki.com.cn/Article/CJFDTotal-STTB201206032.htm [13] 苗红, 张敏.基于GIS缓冲区分析的西北民族地区"非遗"旅游资源空间结构研究[J].干旱区资源与环境, 2014, 28(4):179-186. http://www.cnki.com.cn/Article/CJFDTotal-GHZH201404031.htm -
