铁路货车装载超限的无人机视觉检测技术

汪怡然; 阮欣培; 李鹏舜; 李少爽; 刘雪勇; 杨岳

铁路货车装载超限的无人机视觉检测技术

1.
中南大学交通运输工程学院, 长沙 410075;
2.
中南大学信息科学与工程学院,长沙 410075

基金项目: 国家重点实验室开放课题（2017ZJKF09）

详细信息

作者简介:
汪怡然,在读本科生;阮欣培,在读本科生。

中图分类号: U294.2:TP39
计量
- 文章访问数: 122
- HTML全文浏览量: 5
- PDF下载量: 54
出版历程
- 收稿日期: 2018-05-09
- 刊出日期: 2018-07-24

Unmanned aerial vehicle visual detection technology on gauge-exceeding for railway freight car

1.
School of Traffic and Transportation Engineering, Central South University, Changsha 410075, China;
2.
School of Information Science and Engineering, Central South University, Changsha 410075, China

摘要

摘要: 为了保证铁路运输安全,研究一种铁路货车装载超限的无人机视觉检测技术,高效、简便地实现铁路货车装载超限检测。在构建无人机飞行姿态模型的基础上,利用无人机多角度拍摄铁路货车装载实物图像,基于单目立体视觉和图像数据处理方法还原出货车装载状态的三维实物模型。通过三维实物模型与超限检定模型的嵌套和比对,可一次实现整辆货车各部位装载超限情况的精准判定,避免了人工测量法存在的安全隐患。采用无人机视觉检测技术进行超限检测实验,检测精度可达2 mm,满足现场需求。
- 铁路货车 /
- 无人机 /
- 飞行姿态 /
- 三维重建 /
- 超限检定
Abstract: In order to ensure the safety of railway transportation, unmanned aerial vehicle (UAV) visual detection technology on gauge-exceeding for railway freight car was put forward in this paper. Based on the model of the UAV flight attitude, taking multi angle UAV to photograph railway freight car loading image, the 3D model of railway freight car could be restored on the basis of the monocular stereo vision 3D measurement theory and image data processing methods. After nesting and comparing the reconstructed model with the gauge-exceeding standard model, the gauge-exceeding status of the whole railway freight car could be determined precisely, which avoided the security risks resulting from the manual measurement. The gauge-exceeding inspection experiment demonstrates that the detection precision is up to 2 mm.
- railway freight car /
- unmanned aerial vehicle (UAV) /
- flight attitude /
- 3D model reconstruction /
- gauge-exceeding detection

HTML全文

参考文献(10)

[1]	苟煜林. 铁路现场货物装载超限检测技术研究[D].成都:西南交通大学,2013.
[2]	乔佳. 铁路货车超限检测系统设计[D]. 天津:天津大学,2009.
[3]	张光远,丁小东,鲁工圆,等.基于红外与高速摄像技术相结合的铁路超限检测系统实验分析[J].综合运输,2017,39(7):54-59.
[4]	赵文成,许贤泽,乐意,等.基于双探测器的手持式激光测距仪系统设计与实现[J].中南大学学报(自然科学版),2015,46(8):2843-2849.
[5]	孙丽丽,肖世德.基于结构光原理的铁路货车超限检测算法研究[J].计算机应用,2005(1):213-214,217.
[6]	杜津玲,勾长虹.基于工控机的铁路货车超限测量系统的设计与实现[J].铁路计算机应用,2012,21(9):38-40.
[7]	张益昕,汪家其,王顺,等.基于大尺度三维几何视觉的货运列车超限检测方法研究[J].仪器仪表学报,2012,33(1):181-187.
[8]	Zhijing Yu, Jiwei Ma, Yuquan Ma, et al.Accurate camera intrinsic parameters calibration using virtual stereo board[C]//Proceedings of Photonics Asia 2004,Sensors and Imaging—5633volume.Beijing, China:2004, 12:371-382.
[9]	Matlab摄像机标定工具箱的使用说明[EB/OL].[2015-07-17]. https://wenku.baidu.com/view/89200f7ff90f76c660371a84.html.
[10]	缪盾,吴竞.基于AgisoftPhotoscan的图像三维重建及精度研究[J].测绘工程,2017,26(8):41-44.
