基于Testcase Designer的列车运行控制系统测试方法的研究

陈黎洁; 孙超; 卢利勇; 贺红阳

基于Testcase Designer的列车运行控制系统测试方法的研究

1.
中国铁道科学研究院标准计量研究所,北京 100081;
2.
Multitel ASBL, Mons, Belgium,7000

基金项目: 国家自然科学基金项目（U1434209）；中国铁道科学研究院科研项目（1451ZJ0102）；中国铁道科学研究院科研项目（1551ZJ0804）。

详细信息

作者简介:
陈黎洁，助理研究员；孙超，助理研究员。

中图分类号: U284.482:TP39
计量
- 文章访问数: 127
- HTML全文浏览量: 0
- PDF下载量: 20
出版历程
- 收稿日期: 2016-09-11
- 刊出日期: 2017-01-24

Test method of train control system based on Testcase Designer

1.
Standard & Measurement Research Institute, China Academy of Railway Science, Beijing 100081, China;
2.
Multitel ASBL., Mons 7000, Belgium

摘要

摘要: 针对CTCS-3级列控系统的需求规范，结合欧洲列车运行控制系统（ETCS）的测试经验，研究基于Testcase Designer的CTCS-3级列控系统自动测试方法。Testcase Designer主要用于将测试案例模块化，通过优化编写流程，生成符合测试平台需求的测试序列，为测试项目的执行提供必要的关键数据点。同时，Testcase Designer可供存储、导出及发布。其测试案例中的关键输入输出接口（如BTM、TIU、RTM等）配置信息均已通过配置文件形式实现。以列控系统无线闭塞中心（RBC）切换场景为例，采用Testcase Designer编写该场景的测试案例。研究结果表明：Testcase Designer实现了功能特征、参考需求、测试步骤等元素的集成，编写的测试案例是合理的。
- CTCS-3级列控系统 /
- 测试案例 /
- 运营场景 /
- RBC切换
Abstract: Combining with the testing experiences of European Train Control System (ETCS) and aiming at the requirements specification of CTCS-3 level train control system, this article researched on the automatic testing method of CTCS-3 level train control system based on Testcase Designer. Testcase Designer is mainly applied in modularizing test case to optimize the writing process, form test sequence which could satisfy the requirement of test platform, provide key data points for the execution of test program. At the same time, Testcase Designer could be used for storage, exporting and publishing. The configuration information of key input/output interface in test case (e.g., BTM, TIU, RTM, etc.) were implemented through configuration file. The scenario of RBC handover was taken as an example to write the test case of this scenario with Testcase Designer. The research results showed that Testcase Designer integrated feature, reference requirements and test steps as well as the written test case were reasonable.
- CTCS-3 level train control system /
- test case /
- operational scenario /
- RBC handover

HTML全文

参考文献(8)

[1]	ERTMS / UNISIG: SUBSET026-3, System Requirements Specification, 1-103, February, 2012 [EB/OL].[2012-02-28]. http://www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[2]	ERTMS / UNISIG: SUBSET076-2, Methodology to prepare features, l – 16, February, 2012 [EB/OL].[2012-02-28]. http: //www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[3]	ERTMS / UNISIG: SUBSET076 - 3, Methodology of testing, l-20, February, 2012. [EB/OL].[2012-02-28]. http: //www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[4]	ERTMS / UNISIG: SUBSET076-4-1,Test sequence generation: Methodology and Rules, l – 34, February, 2012 [EB/OL].[2012-02-28]. http: //www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[5]	ERTMS / UNISIG: SUBSET076-7, Test Sequences Validation and Evaluation, l-13, February, 2012 [EB/OL]. [2012-02-28]. http: //www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[6]	ERTMS / UNISIG: SUBSET094, Functional requirements for an on-board reference test facility, 1-65, May, 2014 [EB/OL].[2012-05-30]. http: //www.era. europa. eu/core/ertms/Pages/Approved Documents List of informative specifications.aspx.
[7]	中华人民共和国铁道部科学技术司，中华人民共和国铁道部运输局. CTCS-3 级列控系统需求规范（v1.0）：科技运[2008]127 号[S]. 北京：中华人民共和国铁道部科学技术司，中华人民共和国铁道部运输局，2008，8.
[8]	牛儒, 曹源, 唐涛. ETCS-2 级列控系统RBC 交接协议的形式化分析 [J]. 铁道学报, 2009, 31（ 4）：52 - 58.
