地铁信号设备在线监测系统设计与实现

详细信息

Design and implementation of Online Monitoring System for signal devices of metro

1.
Research and Development of Metro Operation Technology, Beijing Metro Operation Co., Ltd., Beijing 102208, China;
2.
Hangzhou Huijing Technology Co., Ltd., Hangzhou 310000, China

摘要: 通过多种类传感器技术实时获取信号设备运行基础数据,利用无线通信、网络等技术实现数据传输,搭建地铁信号设备在线监测系统。系统具有对道岔、转辙机、有源应答器、轨道电路以及信号设备、电源设备和系统的实时监测功能,有利于信号设备维护和管理人员远程实时监测运营信号设备的运行状态,便于设备运用、维护与诊断。
- 地铁 /
- 信号设备 /
- 在线监测 /
- 道岔 /
- 轨道电路 /
- 有源应答器
Abstract: The real-time running data of signal equipment was obtained by using multiple kinds of sensor technology, and transmitted by using wireless communication and network technologies. The paper introduced the Online Monitoring System for signal devices of metro. The System was with real-time monitoring functions to turnout, switch machine, active balise, the track circuit, signal equipment, power equipment and system. It was beneficial to remote real-time monitoring operation signal equipment, and facilitated the use, maintenance and fault diagnosis of equipment.
- metro /
- signal devices /
- online monitoring /
- turnout /
- track circuit /
- active transponder

[1]	中国城市轨道交通年度报告课题组.中国城市轨道交通年度报告2012 [M].北京：中国铁道出版社, 2012.
[2]	马全松,秦亚明,杨云国.TJWX-2000型信号微机监测系统设计[J].铁道学报,2003（1）：54-58.
[3]	刘彦斌,彭强. 基于PC104的铁路道岔监测系统的设计与实现[J].铁路计算机应用,2007（8）：20-22.
[4]	陆欣,丁晓明,裘正定. CAN总线在道岔密贴缺口监测系统中的应用[J].铁路通信信号,2007,43（6）：20-21.
[5]	王立延.LWJ2000铁路信号微机监测系统[J].铁路计算机应用,2004,13（5）：39-40.
[6]	郑林.铁路信号微机监测计算机辅助设计[J]. 铁路计算机应用,2005,14（5）.
[7]	张杰,李家才.计算机网络在铁路信号中的应用[J].铁道通信信号,2002,38（12）：1-3.
