AMOS-6000工控机多屏显示的设计及应用

邱锡宏, 秦玉利

邱锡宏, 秦玉利. AMOS-6000工控机多屏显示的设计及应用[J]. 铁路计算机应用, 2019, 28(5): 37-40.
引用本文: 邱锡宏, 秦玉利. AMOS-6000工控机多屏显示的设计及应用[J]. 铁路计算机应用, 2019, 28(5): 37-40.
QIU Xihong, QIN Yuli. Multi-screen display for AMOS-6000 industrial person computer[J]. Railway Computer Application, 2019, 28(5): 37-40.
Citation: QIU Xihong, QIN Yuli. Multi-screen display for AMOS-6000 industrial person computer[J]. Railway Computer Application, 2019, 28(5): 37-40.

AMOS-6000工控机多屏显示的设计及应用

基金项目:

中国铁路总公司重大课题(2016X003-E)

详细信息
    作者简介:

    邱锡宏,高级工程师;秦玉利,高级工程师。

  • 中图分类号: U284.3;TP39

Multi-screen display for AMOS-6000 industrial person computer

  • 摘要: 计算机联锁系统的操作显示界面需完整显示所控制对象的站场形状,对于规模较大的站场,单台显示器的显示效果较差,图形、文本紧缩,不便于操作和识别。通过将AMOS-6000工控机的多屏显示硬件高清视频接口(HDMI)修改为视频图像阵列(VGA)接口方式,针对DOS系统,采用基本输入输出系统(BIOS)驱动和基本图像接口(BGI)文件,实现多台显示器组合显示图形。该方案在京沪既有普速铁路线的工程实践中得到应用,满足铁路枢纽车站、编组站等大型站场的操作显示需求。
    Abstract: The operation interface of computer interlocking system needs to display the shape of the station and yard of the controlled object. For large-scale stations, the display effect of single display is poor, the graphics and text are compact, and it is not easy to operate and recognize. By modifying the multi-screen display hardware HDMI of AMOS-6000 industrial person computer to the video graphics Array (VGA) interface mode, the basic input and output system (BIOS) driver and basic graphics interface (BGI) file were used to implement the combination display of multiple displays for the DOS system. The scheme was applied in the engineering practice of Beijing-Shanghai existing general speed railway line, could meet the operation and display requirements of railway hub stations, marshalling stations and other large stations.
  • [1] 中国铁路总公司. 车站计算机联锁操作显示技术规范:TJ/DW 188-2016[S]. 北京:中国铁路总公司, 2016.
    [2] 国家铁路局. 铁路车站计算机联锁技术条件:TB/T 3027-2015[S]. 北京:中国铁道出版社, 2015.
    [3] 朱迎春,张程. 计算机联锁操作显示屏适配分析[J]. 铁道通信信号, 2016, 52(Z2):118-119.
    [4] 周升锋,李立新,孙传俊.Turbo C/Borland C++用户界面程序设计[M]. 西安:西安交通大学出版社, 1994.
    [5] 刘子良. 计算机硬件系统设计原理[M]. 北京:高等教育出版社, 2016.
    [6] 葛学仁,王长海. 计算机联锁车站控制台显示黑屏故障的处理[J]. 铁路计算机应用, 2011, 20(3):23-25.
    [7] 许耀山. 电子产品PCB可制造性设计方法[J]. 电子科技, 2012, 25(11):63-65.
    [8] 刘德贵,杨宝琪. DOS/BIOS使用详解(修订本)[M]. 北京:电子工业出版社, 1994.
    [9]

    Video Electronics Standards Association. VESA BIOS EXTENSION (VBE)-Core Functions Standard, Version:3.0[Z/OL].[1998-09-01]. http://www.vesa.org.

    [10] 张秉帅,李坤,杨淘,等. 以ATS为核心的站场图数据及显示方案的研究[J]. 铁路计算机应用,2014,23(6):5-9.
  • 期刊类型引用(1)

    1. 刘著. 地铁无人值守全自动洗车机改造方案研究. 农业装备与车辆工程. 2025(01): 156-159 . 百度学术

    其他类型引用(0)

计量
  • 文章访问数:  63
  • HTML全文浏览量:  0
  • PDF下载量:  7
  • 被引次数: 1
出版历程
  • 收稿日期:  2018-05-29
